tert-Butyl 2,6-diazaspiro[4.5]decane-6-carboxylate
![Structure image for tert-Butyl 2,6-diazaspiro[4.5]decane-6-carboxylate](/uploads/upload/20241201/24120115441US.png)
![Appearance image for tert-Butyl 2,6-diazaspiro[4.5]decane-6-carboxylate](/uploads/upload/20241201/24120115442D18.jpg)
Product Specifications
- CAS
- 960294-16-0
- Molecular Formula
- C13H24N2O2
- Appearance
- colorless to pale-yellow liquid
- Synonym(s)
- tert-butyl 2,6-diazaspiro[4.5]decane-6-carboxylate；2,6-Diazaspiro[4.5]decane-6-carboxylicacid1,1-dimethylethylester; 2,6-Diazaspiro[4.5]decane-6-carboxylicacidtert-butylester; 6-Boc-2,6-diazaspiro[4.5]decane; 2,6-Diazaspiro[4.5]decane-6-carboxylicacidtert-butylester
- Shipping
- 2-8°C
- Storage
- 2-8°C
- SMILES
- CC(C)(C)OC(=O)N1CCCCC12CCNC2
- InChI
- InChI=1S/C13H24N2O2/c1-12(2,3)17-11(16)15-9-5-4-6-13(15)7-8-14-10-13/h14H,4-10H2,1-3H3
Product Information
tert-Butyl 2,6-diazaspiro[4.5]decane-6-carboxylate is linked to CAS 960294-16-0 and molecular formula C13H24N2O2. PubChem returns a single compound, CID 22291243, with molecular weight 240.34. It records SMILES CC(C)(C)OC(=O)N1CCCCC12CCNC2 and InChIKey HQYFHYDDVSZPPP-UHFFFAOYSA-N. The official synonym set includes 6-Boc-2,6-diazaspiro[4.5]decane, connecting the abbreviated catalog wording to this full title.
The spiro[4.5] framework consists of a five-membered ring and a six-membered ring sharing one central atom. Nitrogens occupy positions 2 and 6. The nitrogen at position 6 is bonded to the carboxylate carbonyl, whose second oxygen carries the tert-butyl group; this is the connectivity summarized by the Boc abbreviation. The other ring nitrogen remains unprotected in the neutral graph. Formula C13H24N2O2 contains no separate acid or counterion, and the PubChem representation has one connected component with no defined stereochemical layer.
When sending a record-specific inquiry to Rlavie, state CAS 960294-16-0, the expanded tert-butyl carboxylate name, and the requested quantity. Include a MOL or SDF structure file so both ring sizes, the shared spiro atom, and the protected position can be checked against PubChem CID 22291243, the SMILES, and InChIKey HQYFHYDDVSZPPP-UHFFFAOYSA-N. Confirming that position 6 bears the carbamate connection should precede review of request-specific information. The shorthand “6-Boc diazaspirodecane” remains a cross-reference but does not display the full bond description.
